Injection System
Injection Molding Is Stable,Easy AdjustmentInjection parts with double guide pillar support structure, smooth two cylinder injection device, shoot and two improved nozzle adjustment easy, can be operated by simple adjustment of the nozzle and the mould center. Injection unit 3 different screw diameter in each group, for customers to choose, fully meet the requirements of personalized processing technology.
Clamping Systems
Efficient And Accurate PositioningOptimization design of oblique line of five fulcrum hyperbolic elbow mold clamping mechanism, power transfer effectively, ensure the process of high speed response. Rapid mold-shut platform but also shorten the molding cycle, improve the production efficiency; Low pressure mold protection system; A variety of hydraulic ejector mode; Can transfer the template support structure; Rod special craft processing, strength and reliable.
Control System
All Monitoring, Full ControlColor LCD display; Abnormal alarm function; Special injection molding machine controller, the double CPU control, control and display CPU are relatively independent, and reliable; Stop button QianHouMen economy; Realtime monitor shows every action operation situation; The system hardware I/O testing function; Special injection molding machine controller; Cylinder temperature deviation corrections; High precision displacement sensor system.
Hydraulic System
Ease Of Maintenance, Compact StructureLow noise quantitative pump system The oil temperature deviation alarm function Tank level gauge Hydraulic oil cooling unit
| ITEM |
UNIT |
DATA |
| Injection Unit |
Screw Diameter |
mm |
34 |
36 |
40 |
| Screw L/D Ratio |
L/D |
21.1 |
20 |
18 |
| Injection Volume |
cm3 |
110 |
125 |
154 |
| Shot Weight |
g |
100 |
114 |
140 |
| Injection Pressure |
Mpa |
180 |
160 |
130 |
| Clamping Unit |
Clamping Force |
kN |
780 |
| Opening Stroke |
mm |
300 |
| Mould Thickness(Min-Max) |
mm |
150-300 |
| Space Between Tie-Bars |
mm |
330×330 |
| Ejector Force |
kN |
25 |
| Ejector Stroke |
mm |
80 |
| General |
Motor Power |
kW |
9 |
| Heater |
kW |
6.5 |
| Pump Pressure |
Mpa |
16 |
| Machine Dimension |
m |
4.0×1.1×1.8 |
| Machine Weight |
T |
2.5 |
| Mould Orientation Ring Diameter |
mm |
Φ100 |
| Nozzle Radius |
mm |
SR10 |
